MIL-PRF-83504/7C
Terminal sealing and solderability: The terminal potting material meniscus may extend to .030 inch
maximum beyond the solder standoff.
Dimensions and configuration: See figure 1 and table I.
Seal: Sealed base. Temporary tape top seal.
Switch position and setting identification: See figure 1.
Orientation: See figure 1.
Operating force: 24-64 ounces.
Electrical ratings:
10 mA maximum at 50 mV, switching (resistive load)
100 mA maximum at 6 V dc, switching (resistive load)
25 mA maximum at 24 V dc, switching (resistive load).
Application note: In applications where the switch will mate with sockets or with panel boards, the user
should consider the compatibility of the mating terminals with respect to finished and mechanical
configurations.
Part or Identifying Number (PIN): M83504/07- (and dash number from table I).
TABLE I. Dash numbers and characteristics
Dash number
Number
Terminal finish
Dimension
of
"A" inches (mm)
Gold 1/
stations
Solderable
(Plug-in)
001
021
2
.380
(9.65)
002
022
3
.780
(19.81)
1/ PIN's for switches equipped with gold terminations are
inactive for new design.
Custodians:
Preparing activity:
Army - CR
DLA - CC
Navy - EC
Air Force - 11
(Project 5930-1128-06)
DLA - CC
Review activities:
Army - AR, AV, MI
Navy - AS
Air Force - 99
