MIL-PRF-24236/2J
REQUIREMENTS:
Dimensions and configuration: See figure 1 and table I.
Operating temperature range: -75°F to +500°F.
Exposure temperature: -85°F to +500°F.
Class: 4, except 30 g's for configuration 5 only.
Mounting: See figure 1.
Weight: Approximately .21 pound (95.26 grams).
Operating temperature and tolerances: See table II and table III.
Torque:
Connector: 8 foot-pounds.
Switch mounting: 15 foot-pounds.
Electrical ratings:
Figure 1, configurations 1 through 4. See table IV.
Figure 1, configuration 5. 1/
Load: 2 amperes, resistive.
Intermediate current: Applicable 25,000 cycles.
Low level: Applicable 50,000 cycles.
Endurance: See table IV.
TABLE I. Configuration and contact action.
Configuration
Contact action
1
2
3
4
5
Code
A
C
E
G
J
Open on increasing temperature
Code
B
D
F
H
K
Close on increasing temperature
Code
A
C
E
G
J
Close on decreasing temperature
Code
B
D
F
H
K
Open on decreasing temperature
_______
1/ Switches shall be subjected only to low level loads prior to delivery for use.
6
