INCH-POUND
MIL-PRF-22885/59E
28 April 2004
SUPERSEDING
MIL-PRF-22885/59D
17 MARCH 1999
PERFORMANCE SPECIFICATION SHEET
SWITCH, PUSHBUTTON, ILLUMINATED,
2-LAMP, LENS ARRANGEMENTS FOR
This specification sheet is approved for use by all Departments
and Agencies of the Department of Defense.
The requirements for acquiring the lens arrangements described herein
shall consist of this specification sheet and MIL-PRF-22885.
.740
Inches
mm
.050
1.27
.485
12.32
.740
8.80
NOTES:
1. Dimensions are in inches.
2. Metric equivalents are given for general information only.
3. Unless otherwise specified, tolerance is ±.010 (.25 mm).
FIGURE 1. Front lens plate.
AMSC N/A
FSC 5930
