MIL-PRF-22885/16F
Plunger stop. Shall be readily adjustable or removable in the field without the need of special tools. Plunger stop
shall be removed when switching is required when indicator light is coupled to a switch assembly.
Plunger stop test. With the plunger stop functionally installed in the lamp module, and the lamp module mounted by
its normal mounting means, a static force of 25 pounds shall be applied to the legend plate for 1 minute. The plunger
stop shall restrict normal actuator travel.
QUALIFICATION
Qualification inspection shall be performed on the complete assembly as required by MIL-PRF-22885/15 using the
applicable modular switch subassemblies.
TABLE IV. Part number and design characteristics.
Part number 1/ 2/
Mounting arrangement
Lens
Circuit schematic
(configuration)
plate code
code
M22885/16
-01(XXXX)
A
A
1
-02(XXXX)
B
A
1
-03(XXXX)
A
A
2
-04(XXXX)
B
A
2
-05(XXXX)
A
B
1
-06(XXXX)
B
B
1
-07(XXXX)
A
B
2
-08(XXXX)
B
B
2
-09(XXXX)
C
1
-10(XXXX)
B
C
1
-11(XXXX)
A
C
3
-12(XXXX)
B
C
3
-13(XXXX)
A
A
3
-14(XXXX)
B
A
3
-15(XXXX)
A
A
4
-16(XXXX)
B
A
4
-17(XXXX)
A
B
4
-18(XXXX)
B
B
4
-19(XXXX)
A
C
4
-20(XXXX)
B
C
4
1/ Part numbers shown are for operator/indicators without color filters. When color filters are
required, add the color symbols of MIL-PRF-22885 in place of "(XXXX)" with the location
as shown on figure 3.
Example: M22885/16-11RRGG.
2/ These part numbers are interchangeable with and replace former part numbers which
contained an additional zero.
Intended use: The operator-indicators are intended for use as illuminated indicators and for use as illuminated
operator/indicators when used with MIL-PRF-22885/11 modular switch sub-assemblies.
5
