MIL-PRF-22710/24B
Truth table 1/
Binary coded decimal plus compliment
Common C
Dial
Conn to:
marking
1
2
4
8
1
2
4
8
INCHES
MM
0
.250
6.35
1
.580
14.73
2
1.050
26.67
3
1.146
29.11
4
5
6
7
8
9
1/ Code explanation: Dial reads 0 - Common C active with terminals 1, 2, 4 and 8
Dial reads 1 - Common C active with terminals 1, 2, 4 and 8.
Dial reads 2 - Common C active with terminals 2, 1, 4 and 8.
and so forth.
NOTES
1. Dimensions are in inches.
2. Metric equivalents are given for general information only and are base upon 1 inch =
25.4 mm.
Circuit configuration 4
FIGURE 4. Module and circuit configuration - Continued.
9
