MIL-PRF-22710/14F
Number of
Dimensions
stations
-.00
A (MAX)
B
D
C
.03
+.03
1
1.40
( 35.56)
0.984 ( 24.99)
0.70 ( 17.79)
0.75 ( 19.10)
2
1.90
( 48.26)
1.486 ( 37.74)
1.20 ( 30.48)
1.25 ( 31.80)
3
2.40
( 76.20)
1.988 ( 50.50)
1.70 ( 43.18)
1.75 ( 44.50)
4
2.90
( 60.96)
2.490 ( 63.25)
2.20 ( 55.88)
2.25 ( 57.20)
5
3.40
( 73.66)
2.992 ( 76.00)
2.70 (68.58)
2.76 ( 70.10)
6
3.90
( 99.06)
3.94 ( 88.75)
3.20 (81.28)
3.26 (82.80)
7
4.40
(111.76)
3.996 (101.50)
3.70 (93.98)
3.76 ( 95.50)
8
4.90
(124.46)
4.498 (114.25)
4.20 (106.68)
4.26 (108.20)
9
5.40
(137.16)
5.000 (127.00)
4.70 (119.38)
4.76 (120.90)
10
5.90
(149.86)
5.502 (139.75)
5.20 (132.08)
5.26 (133.60)
NOTES:
1. Dimensions are in inches.
2. Metric equivalents are in parentheses.
3. Metric equivalents are given for general information only and are base upon 1 inch = 25.4 mm.
4. Unless otherwise specified, tolerance it .101 (.25 mm).
5. Black matte finish over silver - for all surfaces exposed from front of panel.
6. No color coating to be applied over silver in this area (2 places).
7. No paint .25/.35 diameter.
8. .049 .002 DIA, drilled out holes.
9. Minimum silvered surface, measured from front of switch.
10. Panel cutout dimensions shown in table
FIGURE 2. RFI Shielded switch and panel cut-out
3
