MIL-DTL-83731/13D
Military Part or Identifying Number (PIN): The PIN shall consist of the prefix M83731/13 followed in order by the
appropriate three-digit number from table II as shown in the following example:
M
83731/13
-
211
|
|
|
Military designation_____|
|
|
|
|
Specification sheet number
|
|______________Number from table II denotes
Switch has ON-OFF-ON circuit.
1/ Listed dash numbers, ending with the number 1, are interchangeable with and supersede canceled dash numbers
ending with the numbers 2 and 3.
TABLE II. Circuit for switching characteristic.
Circuit with toggle in
Circuit
Down position
Center
Up position
211
1-2 ON
OFF
2-3 ON
231
1-2 ON
NONE
2-3 ON
261
1-2 MOM-ON
NONE
2-3 ON
271
1-2 MOM-ON
OFF
2-3 MOM-ON
311
1-2 MOM-ON
OFF
2-3 ON
341
1-2 ON
2-3 ON
NONE
The margins of this specification are marked with vertical lines to indicate where modifications were made. This was
done as a convenience only and the Government assumes no liability whatsoever for any inaccuracies in these
notations. Bidders and contractors are cautioned to evaluate the requirements of this document based on the entire
content irrespective of the marginal notations.
Referenced Documents:
MIL-DTL-83731
MIL-STD-202
ANSI J-STD-004
EIA RS-448-4
Custodians:
Preparing activity:
Army - CR
DLA - CC
Air force - 11
DLA - CC
(Project 5930-2007-027)
Review activities:
Army - AR
Air force - 99
NOTE: The activities listed above were interested in this document as of the date of this document. Since
organizations and responsibilities can change, you should verify the currency of the information above using the
ASSIST Online database at https://assist.daps.dla.mil.
4
