MIL-DTL-5423/6D
REQUIREMENTS:
Dimensions and configuration: See figure 1.
Silicon rubber: Grade 50.
Part or Identifying Number (PIN): See table I.
TABLE I. Size and PIN's.
Dimensions
PIN
M5423/06-
Size
A
B
1/ 1
.438 (11.18)
.625-27 UNS-2A
01
1/ 2
.688 (17.48)
.625-27 UNS-2A
02
3
.438 (11.18)
.625-24 UNS-2A
03
4
.688 (17.48)
.625-24 UNS-2A
04
1/ Inactive for new design.
Qualification: First Article Testing in accordance with MIL-DTL-5423.
