MIL-DTL-5423/13D
REQUIREMENTS
Dimensions and configuration: See figure 1.
Silicon rubber: Grade 50, class III, transparent.
Splashproof: In accordance with MIL-STD-108, table I.
Endurance: 10,000 operations. Minute cracks after life test, which do not permit leakage, shall not be cause for
rejection.
Part or Identifying Number (PIN): See tables I and II.
Table I. Dimensions.
PIN
Dimensions ±.031 (.79)
M5423/13-
L1
W1
W2
L2
01
1.250 (31.75)
.750 (19.05)
.531 (13.49)
.60 (15.24)
02
1.312 (33.32)
1.500 (38.10)
1.250 (31.75)
.60 (15.24)
03
1.281 (32.54)
2.250 (57.15)
2.000 (50.80)
.60 (15.24)
Table II. Mounting holes, markings, and panel cutout.
Mounting holes
Panel cutout
PIN
Markings
Location
Number of
M5423/13-
screws
X
Y
B
B1
01
2
Yes
None
None
1.250 (31.75)
.531 (13.49)
02
4
None .375 (9.53)
On-off
1.312 (33.32)
1.250 (31.75)
03
6
Yes
.750 (19.05)
None
1.281 (32.54)
2.000 (50.80)
Qualification: First Article Testing in accordance with MIL-DTL-5423.
3
For Parts Inquires call Parts Hangar, Inc (727) 493-0744
