MIL-DTL-3786/3G
REQUIREMENTS:
Dimensions and configurations: See figures 1 and 2.
Angle of throw: 30°, 36°, 45°, 60°, and 90°.
Terminals: The terminal tabs shall be bent at an angle of 60 ±15 degrees from the plane of the
section. When flat terminals are required, the dimensions shall be as shown on figure 1.
Rotational torque: The minimum and maximum values of torque determined for shaft rotation shall be
within the limits specified in table I. The rotational torque shall not change more than ±50 percent from
its initial value and shall be not less than the minimum torque specified.
TABLE I. Rotational-torque limits.
Torque (pound-inch)
Temperature
Minimum Maximum
Room
1
6
Minimum
1
8
Construction type: See table IV.
Number of poles per deck: See table VI.
Number of positions: See table VI.
Life (rotational): The test loads for the applicable circuit conditions shall be as specified in table II.
Each of the loads, specified for the applicable environmental condition, shall be switched by at least
one rotor contact of the switch.
TABLE II. Electrical loads.
Inductive load
Resistive load
Environmental condition
Milliamperes
Volts, dc
Milliamperes
Volts
500
28 V dc
At atmospheric pressure
50
28
225
115 V rms
50
300 V rms
350
28 V dc
At reduced barometric
---
---
100
115 V rms
pressure
Dielectric withstanding voltage: The applicable test voltage specified in table III shall be applied
between the general switch elements.
TABLE III. Dielectric-test voltages.
Altitude
Test voltage
Volts, rms
At atmospheric pressure
1,000
At reduced barometric pressure
400
5
