INCH-POUND
MIL-DTL-3786/2G
26 January 2011
SUPERSEDING
MIL-DTL-3786/2F
19 November 2004
DETAIL SPECIFICATION SHEET
SWITCH, ROTARY, OPEN CONSTRUCTION, ½ AMPERE,
STYLE SR02
Inactive for new design after 8 March 1999
This specification is approved for use by all Departments and Agencies of the Department of Defense.
The requirements for acquiring the switch described herein shall consist of this specification sheet and
MIL-DTL-3786.
FIGURE 1. Style SR02 switch.
AMSC N/A
FSC 5930
