MIL-DTL-3786/10E
Dielectric withstanding voltage: The applicable test voltage specified in table III shall be applied
between the general switch elements.
TABLE III. Dielectric-test voltages.
Altitude
(Volts, rms) (60 Hz)
At atmospheric pressure
1,000
At reduced barometric pressure
400
Part number: The military part number shall consist of M3786/10- (selected from tables IV through VI)
as shown in the follow example (see note):
M3786/10- A
02
01
Construction type, temperature life
characteristics, shock type and
insulation material (see table IV).
Poles per deck, number of positions and
original angle of throw (see table V).
Number of decks and switching
characteristics (see table VI).
NOTE: Part numbers listed are for style SR010-1 switches. M3786/10-A0201 identifies a rotary switch
of construction type N, temperature-life characteristic B, shock type H, and plastic insulation material;
one pole per deck, two positions per pole, 20° angle of throw; one deck with nonshorting switching
characteristic.
TABLE IV. Code letters for combination of construction type, temperature-life
characteristic, shock type, and insulation material.
Temperature-life
Insulation
Code letter
Construction type
characteristics
Shock type
material
A
N
B
H
P
B
S
"
H
"
C
N
"
M
"
D
S
"
M
"
5
