MIL-DTL-15743/8C
REQUIREMENTS
SYMBOL NUMBER: See table I.
DESIGN:
Electrical rating: 500 V ac, 60 Hz, 250 V dc, 0-30 ampere.
Dimensions and configuration: See figures 1 through 9.
Wiring diagram: See figure 10.
Mounting dimensions: See figure 9.
Degree of enclosure: Submersible (15 feet).
Weight: 5 pounds maximum.
Designation and marking: See figure 10 and 11.
Identification data shall be blank. as shown on figure 11. Unless otherwise specified in the ordering
data, switch action marking shall be blank
Parts: The parts shown in table II and as specified in MIL-DTL-15743 shall be used in the
construction of the switches specified herein.
GENERAL INFORMATION:
Military part number and general information are as shown in table I.
TABLE I. Military part number and general information.
Supersedes 1/
Military
Symbol
No. of poles and switching
part no.
no.
characteristics
Type
M15743/8-001
838.1
DPDT
3SR2C4A-2
M15743/8-002
840.1
DPDT
3SR2C4-2
M15743/8-003
851
TPST
3SR3A4-2
1/ From NAVSEA Drawing 9000-S6202-74276.
ORDERING DATA:
Acquisition documents should specify the following:
Switch action marking, if required (see requirements).
9
