MIL-DTL-15743/7C
REQUIREMENTS
SYMBOL NUMBER: See table I.
DESIGN:
Electrical rating: 125 V ac, 0-10 ampere, 60 Hz.
Dimensions and configuration: See figures 1 through 9.
Wiring diagram: See figure 11.
Mounting dimensions: See figure 10.
Degree of enclosure: Splashproof.
Weight: 3 pounds maximum.
Designation and marking: See figure 11 and 12.
Identification data shall be as shown on figure 12. Unless otherwise specified in the ordering data,
ON-OFF switch action marking shall be as shown on figure 11.
Parts: The parts shown in table II and as specified in MIL-DTL-15743 shall be used in the
construction of the switches specified herein.
GENERAL INFORMATION:
Military part number and general information are as shown in table I.
TABLE I. Military part number and general information.
Military
Symbol
No. of poles and switching
Supersedes 1/
part no.
no.
characteristics
Type
M15743/7-001
814
DPST
1SR2A4-4
1/ From NAVSEA Drawing 9000-S6202-74207.
ORDERING DATA:
Acquisition documents should specify the following:
Switch action marking, if required (see requirements).
8
