MIL-DTL-15743/21A
TABLE II. Parts list.
Quantity
Description
M15743/
Item
Material/
Remarks
no. 1/
21-001
specification
01
Switch, enclosed
-
----
----
02
Enclosure
1
MIL-E-24142/5
M24142/5-003
Mod 2/
03
Seal, gland
1
MIL-B-5423/9
M5423/09-04
04
Switch (type S2JL3) 3/
1
MIL-S-21604/3(rotor 2)
See figure 4a
05
Switch (type S3JL5) 3/
1
MIL-S-21604/3(rotor 2)
See figure 4a
06
Switch (type S2JL10) 3/
1
MIL-S-21604/3(rotor 2)
See figure 4a
07
Switch (type S3JL3) 3/
1
MIL-S-21604/3(rotor 3)
See figure 4b
08
Switch (type S3JL5) 3/
1
MIL-S-21604/3(rotor 3)
See figure 4b
09
Switch (type S3JL10) 3/
1
MIL-S-21604/3(rotor 3)
See figure 4b
10
Switch (type S4JL3) 3/
1
MIL-S-21604/3(rotor 4)
See figure 4c
11
Switch (type S4JL5) 3/
1
MIL-S-21604/3(rotor 4)
See figure 4c
12
Switch (type S4JL10) 3/
1
MIL-S-21604/3(rotor 4)
See figure 4c
13
Identification plate
1
Brass, ASTM B 36,
See figure 6
ASTM B 121
14
Plate 4/
1
CRES, or equivalent
Size as reqd
1/ Numbers in circles shown on the figures are the same as the item numbers shown in this table.
2/ Modified cover for military part numbers M15743/21-003, -006, and -009 (10 - section switches)
shall be modified as shown on figure 3A.
3/ Stops on JL switches shall be set to agree with the engraving on the identification plate
(see figure 6).
4/ Used only with switches, items 06, 09, and 12.
