MIL-DTL-15743/18B
REQUIREMENTS
SYMBOL NUMBER: See table I.
DESIGN:
Electrical rating: 125 V ac, 0-10 ampere, 60 Hz.
Dimensions and configuration: See figures 1 through 4.
Wiring diagram: See figure 6.
Mounting dimensions: See figure 5.
Degree of enclosure: Submersible (15 feet).
Weight: 4 pounds maximum.
Designation and marking: See figures 7.
Identification data shall be as shown on figure 7. Unless otherwise specified in the ordering data,
switch action and function marking shall be blank.
Parts: The parts shown in table II and as specified in MIL-DTL-15743 shall be used in the
construction of the switch specified herein.
GENERAL INFORMATION:
Military part number and general information are as shown in table I.
TABLE I. Military part number and general information.
No. of poles and
Symbol
Supersedes 1/
Military
switching
no.
part no.
Type
Revision
Date
characteristics
M15743/18-001
2639.1
Six-pole, 2 position
S2JR3-2
H
7/10/80
1/ From NAVSEA Drawing 803-74055.
ORDERING DATA:
Acquisition documents should specify the following:
Switch action and function marking, if required.
7
