MIL-DTL-15743/13C
REQUIREMENTS
SYMBOL NUMBER: See table I.
DESIGN:
Electrical rating: 125 V ac, 0-30 ampere, 60 Hz.
Dimensions and configuration: See figures 1 through 8.
Wiring diagram: See figure 10.
Mounting dimensions: See figure 9.
Degree of enclosure: Dripproof.
Weight: 16 pounds maximum.
Designation and marking: See figures 11 and 12.
Identification data shall be as shown on figures 11 and 12. Unless otherwise specified in the
ordering data, bottom portion of identification plate shall be blank as shown on figure 12.
Parts: The parts shown in table II and as specified in MIL-DTL-15743 shall be used in the
construction of the switch specified herein.
GENERAL INFORMATION:
Military part number and general information are as shown in table I.
TABLE I. Military part number and general information.
Military
Symbol
No. of poles and switching
Supersedes 1/
part no.
no.
characteristics
Type
M15743/13-001
849
TPDT
3SR3B4-
1/ From NAVSEA Drawing 815-1197224.
ORDERING DATA:
Acquisition documents should specify the following:
Switch action marking, if required (see requirements).
9
