MIL-DTL-15743/11C
TABLE II. Parts list.
Quantity
Remarks
Material/
Description
M15743/1
Item
specification
0-001
no. 1/
01
Switch, enclosed
-
See figure 1
(sym 2753)
M24142/5-003
02
Enclosure
1
Brass,
See figure 2 & 3
MIL-E-24142/5
(modified)
03
O-ring
1
SAE-AS28775-010
----
See figure 4
04
Handle
1
Plastic, black, type
CFI-10 or CFI-5 of
ASTM-D5948
05
Shaft assembly
1
----
See figure 5
06
Shaft
1
Ni-Cu alloy of
M15743/11-06
QQ-N-281
See figure 6
07
Coupler
1
Brass,
ASTM-B36/B36M,
ASTM-B121/B121M
08
Wiring diagram
1
MIL-E-2036
See figure 8
09
Switch (type
1
MIL-DTL-15291/7
M15291/7-003
3SR2A4A)
10
Identification plate
1
ASTM-B36/B36M,
See figure 9
ASTM-B121/B121M
1/ Numbers in circles shown on the figures are the same as the item numbers
shown in this table.
Referenced documents: In addition to MIL-DTL-15743, this document references the following
MIL-DTL-15291/7
MIL-E-2036
MIL-E-24142/5
QQ-N-281
ASTM-B36/B36M
ASTM-B121/B121M
ASTM-D5948
NAVSEA DWG 9000-S6202-74276
The margins of this specification are marked with vertical lines to indicate where changes from the
previous issue were made. This was done as a convenience only and the Government assumes no
liability whatsoever for any inaccuracies in these notations. Bidders and contractors are cautioned to
evaluate the requirements of this document based on the entire content irrespective of the marginal
notations and relationship to the last previous issue.
