MIL-DTL-15743/1C
REQUIREMENTS
SYMBOL NUMBER: See table I.
DESIGN:
Electrical rating: 125 V ac, 0-10 ampere, 60 Hz.
Dimensions and configuration: See figures 1 through 9.
Wiring diagram: See figure 11.
Mounting dimensions: See figure 10.
Degree of enclosure: Submersible (15 feet).
Weight: 2 pounds maximum.
Designation and marking: See figure 12.
Identification data shall be as shown on figure 12. Unless otherwise specified in the ordering data,
switch action marking shall be as shown on figure 12.
Parts: The parts shown in table II shall be used in the construction of the switch specified herein.
GENERAL INFORMATION:
Military part number and general information are as shown in table I.
TABLE I. Military part number and general information.
Supersedes 1/
Military
Symbol
No. of poles
part no.
no.
and switching
Type
characteristics
M15743/1-001
801.1
DPST
1SR2A4-4
1/ From NAVSEA Drawing 9000-S6202-74207.
ORDERING DATA:
Acquisition documents should specify the following:
Switch action marking, if required (see requirements).
8
