INCH-POUND
MIL-DTL-15291/11B
6 February 2006
SUPERSEDING
MIL-S-15291/11A(SH)
22 July 1991
DETAIL SPECIFICATION SHEET
SWITCHES, ROTARY, SNAP ACTION CLASS 20SR FRONT MOUNTED, BACK CONNECTED
Inactive for new design after 17 April 1981. For new design, use MIL-DTL-15291/12
This specification is approved for use by all Departments and Agencies of the Department of Defense.
The complete requirements for acquiring the switch described herein shall consist of this specification and
the latest issue of MIL-DTL-15291.
NOTES:
1. Dimensions are in inches.
2. Unless otherwise specified, tolerance is ± .015.
FIGURE 1. Class 20SR switch (up to 6 studs).
AMSC N/A
FSC 5930
