MIL-DTL-13625/2B
Notes:
1. Type V (Single Pole, Single Throw, pull-latch disconnect, normally closed), Class A (slow make and
break), Grade 2 (open) of procurement specification.
2. 300 Amp resistive load, 150 Amp inductive load.
3. Force required to operate the switch shall be 13 2 pounds.
4. Shall withstand a minimum overload force of 150 pounds without damage.
5. Shall not exceed a maximum weight of 17 ounces.
6. Nut shall not be coated with Black Oxide.
7. Threads shall be in accordance with screw thread standard for FED-STD-H28.
8. Dimensions are in inches. Unless otherwise specified, tolerances are .01 on decimals, 0 30'
on angles.
9. For design feature purposes, this specification sheet takes precedence over procurement
documents referenced herein.
10. This specification sheet is not intended to limit construction to features other than as shown heron
by dimensions, notations or referenced documents.
11. Referenced documents shall be of the issue in effect on the date on invitations for bid.
12. Marking shall consist of the part or identifying number (PIN) and Manufacturer's identification in
accordance with MIL-STD-130.
FIGURE 1 continued.
Supersedes
Part or
Identifying
Former
MS Part No.
Number (PIN)
Part No.
MIL-DTL-13625/2-1
MS27200-1
8339369
The margins of this specification are marked with vertical lines to indicate where modifications from this
amendment were made. This was done as a convenience only and the Government assumes no liability
whatsoever for any inaccuracies in these notations. Bidders and contractors are cautioned to evaluate
the requirements of this document based on the entire content irrespective of the marginal notations.
Referenced documents:
MIL-DTL-13625
MIL-STD-130
FED-STD-H28
Custodian:
Preparing activity:
Army - AT
DLA - CC
DLA CC
(Project 5930-2008-083)
NOTE: The activities listed above were interested in this document as of the date of this document.
Since organizations and responsibilities can change, you should verify the currency of the information
above using the ASSIST Online database at https://assist.daps.dla.mil/ .
