MIL-DTL-12285/1J
TABLE I. Part number to switching temperature tolerance.
Part No.
Former
Switching Temperature
Tolerance ± 5ºF
part no.
165ºF
M12285/1-1
9093851
M12285/1-1
7771274-5
165ºF
M12285/1-2
None
185ºF
M12285/1-3
None
205ºF
M12285/1-4
7771274-3
225ºF
M12285/1-4
9099810
225ºF
M12285/1-5
7771274-1
245ºF
M12285/1-5
8376924
245ºF
M12285/1-6
7771274-6
265ºF
M12285/1-7
8376926
285ºF
M12285/1-7
7771274-4
285ºF
M12285/1-9
7771274-2
305ºF
M12285/1-9
9098177
305ºF
M12285/1-10
7771274-7
325ºF
NOTE: When a shorter sensor is required see MIL-DTL-12285/2.
The margins of this specification are marked with vertical lines to indicate where modifications from this
revision were made. This was done as a convenience only and the Government assumes no liability
whatsoever for any inaccuracies in these notations. Bidders and contractors are cautioned to evaluate
the requirements of this document based on the entire content irrespective of the marginal notations.
Referenced documents
MIL-DTL-12285/2
MIL-DTL-12285
MS27144
MS33800
Custodian:
Preparing activity:
Army - AT
DLA - CC
DLA - CC
(Project 5930-2009-028)
NOTE: The activities listed above were interested in this document as of the date of this document.
Since organizations and responsibilities can change, you should verify the currency of the information
above using the ASSIST Online database at https://assist.daps.dla.mil/ .
2
